Bat echolocation

The vessels in nuclear power plants contain highly radioactive nuclear fuel cores. If cracks appear, it could be an indication that the reactor isn’t working as it should, leading people to worry about its dangerous contents. In an extreme scenario a failure to spot faults could cause vessels to release massive amounts of radiation, which would be catastrophic for the surrounding community if exposed to it.

Just this year around 16,000 cracks were found in the steel reactor pressure vessels in one of the reactors at the Tihange nuclear power complex in Belgium. The reactors were immediately shut down, causing public uproar and resulting in cost-worthy downtime – outcomes which could have been prevented with earlier detection.

Mathematicians Dr Tony Mulholland and Dr Ebrahem Algehyne at the University of Strathclyde in Scotland may have developed a way to help reduce the costs of maintenance with an improved means of detecting structural problems. They have come up with a new mathematical model, based on the way bats detect their environment, which they have used to develop a new ultrasound detector, called a transducer.

The new model has a more intricate design than conventional transducers, and is better at spotting cracks in structures. In the case of power plant inspections, it could "streamline the process and lead to time and cost savings", the researchers say.

How it works

The device works in a similar way to how a bat builds up a picture around itself, by firing out and receiving sound. It is stimulated by an electrical signal, which causes it to vibrate and emit a mechanical wave. The wave then passes through the structure of interest, before being received by a second transducer at the other end that converts the vibration back into an electrical signal.
